Dry cooler for data center liquid cooling, cools server coolant efficiently, waterless, energy-saving, optimizes PUE and protects core IT infrastructure.
01 Modular design:
All components are of modular design that saves the designing and fabrication time. Tailored design are available to meet the customer's needs.
02 Easy Installation:
Lifting eyes are provided for lifting and handling that allows elevated installation in a group. Optimized structure design, minimal steel usage.
03 Control System:
PID controller provided for precise temperature control. VSD (Variable Speed Drive) for fans. Each fan is compartmentalized from each other, the temperature can be controlled separately. The failure of one fan will not affect the running of the other fans. The air short-circuit is not possible.
04 High Reliability:
The metal sheets are reinforced by multiple forming and pressing. It can be handled by crane or forklift. The tubes are hy-draulically expanded to ensure tight contact between tubes and fins which is the key for excellent heat transfer property.
05 Clean Tubes:
The tubes and manifold are clean internally, no discoloration. The interior surface of the coils are 100% inspected by the endoscope.
|
Technical Parameters |
||||
|
|
Working Fluid |
Heat Exchange Capacity |
Test Pressure |
Fin Pitch |
|
Condenser |
HFC |
132-2060 |
32 bar |
2.0/2.4/3.0mm |
|
Dry Cooler |
Ethylene glycol |
95-1260 |
16 bar |
2.0/2.4/3.0mm |
|
Available Spare Parts |
||||
|
Spare Part |
HFC |
Liquid Cooling |
||
|
V Multi-circuit coil |
√ |
√ |
||
|
Fan junction box |
√ |
√ |
||
|
Fan safety switch |
√ |
√ |
||
|
Fan speed control |
√ |
√ |
||
|
Spray/water precooling system |
√ |
√ |
||
|
Flange connection |
|
√ |
||
|
Threaded connection |
|
√ |
||
|
Ball valve drain/vent |
|
√ |
||
Maintance
Customization
SINRUI offers customized radiator design and manufacturing services for mining and industrial applications. For customers who wish to upgrade or modify from the original structure or material, our engineering team can provide technical drawings, performance evaluations, and structure redesign based on specific site conditions.
·We support tailored solutions including:
··Replacement of aluminum cores with copper fin - tube designs for improved durability.
··Adaptation of mounting structures for non - OEM equipment.·
