Home > Injection Molding Cooling

ALL PRODUCTS

Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines
Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines
Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines
Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines
Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines
Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines
Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines
Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines

Copper Tube V Type Tube Fin Dry Fluid Cooler for Injection Machines and Printing Lines

High-efficiency dry cooler for injection molding, cools molds & hydraulic systems stably. Water-free design avoids scaling, with compact structure and low maintenance for non-stop industrial molding work.

Inquiry
  • Overview
  • Technical Parameters
  • Maintance & Customization
  • Recommended Products
Our Copper Tube V Type Tube Fin Dry Fluid Cooler is a dedicated high-efficiency cooling solution for injection machines and printing lines. Tailored to the continuous high-load working characteristics of these equipment, it ensures stable process temperature control and improves production efficiency.

Core Features & Advantages

Adopts high-purity copper tubes with excellent thermal conductivity, matching V-type fin structure to maximize heat exchange area and efficiency. Compact design saves installation space, suitable for workshop layout constraints. Anti-corrosion hydrophilic aluminum fins and sealed structure enhance durability, adapting to industrial workshop environments. Low-noise energy-saving fans reduce operation costs; flexible interface design enables quick matching with various injection machine and printing line models.

Working Principle

Adopts closed dry air-cooled circulation: high-temperature fluid from equipment enters the copper tube heat exchange core, fans drive air to flow through V-type fins for rapid heat transfer. Cooled fluid circulates back to the equipment to complete the cooling cycle, realizing precise constant-temperature protection without medium leakage.
Reliable cooling guarantee for injection molding and printing production, ideal for improving product quality and equipment service life.

Dry cooler for Injection molding machine factory

Heat Transfer capacity: 694kw

Cooling medium: water

Medium volume: 60l/s

Inlet medium temp: 35

Outlet medium temp: 25

Inlet air temp: 20

Power Supply: 400v/3ph/50Hz

Material: copper tube aluminum fin galvanized sheet frame

Maintance

    • Warranty Coverage: 1-year warranty. Free repair/replacement for non-human faults—no extra costs.
    • Maintenance Support: Online help for daily issues. Certified techs sent on-site if needed. Genuine spare parts supplied long-term.
    • Testing Services: Leak, pressure, and heat tests before delivery. On-site inspection available upon request.

Customization

SINRUI offers customized radiator design and manufacturing services for mining and industrial applications. For customers who wish to upgrade or modify from the original structure or material, our engineering team can provide technical drawings, performance evaluations, and structure redesign based on specific site conditions.

·We support tailored solutions including:

··Replacement of aluminum cores with copper fin - tube designs for improved durability.

··Adaptation of mounting structures for non - OEM equipment.
